Entrust Sigma DS3 Duplex

The world’s most enhanced card printing solution

Entrust Sigma card printers represent the next generation of direct-to-card printing. Easy to operate, with industry-leading security features, modular and packed with convenient printing options, they easily take your card issuance to the next level. Available in three model-series: the Sigma DS1, Sigma DS2 and Sigma DS3.

  • + Simple
  • + Secure
  • + Smart

Sigma DS3 Duplex:
The fastest printer in the Sigma series. Equipped with Ethernet and Duplex (for double-sided printing). Optional Laminator (for extra card protection) and a Tactile module for a tactile security feature.

Description :

General: The Entrust Sigma DS3 Duplex has a built-in flipper module. This allows you to print both sides of the card in one operation. The Entrust Sigma DS3 Duplex card printer is the latest successor to the popular and successful Datacard SD360 and Datacard CD800. It is the most powerful card printer in the DS series and can be expanded with numerous encoders and options. With its more reliable technology and excellent print resolution, the Entrust Sigma DS3 Duplex Card Printer is ideal for a wide range of applications. With the latest technologies, your new Sigma DS3 Duplex card printer is future-proofed and ready for the challenges ahead.


Technology: The new TrueMatch printing technology ensures vivid, brilliant and crisp prints with the Entrust Sigma DS3 Duplex . The Entrust Sigma DS3 Duplex printer reliably produces high-quality images by mimicking the RGB colour space. Optionally, the card printer can be equipped with WiFi, which offers even greater flexibility. Thanks to the new TruePick card technology, card jams are virtually eliminated, which prevents unnecessary misprints. The Sigma DS3 Duplex is one of the fastest card printers in its class. As with the two smaller models, the Sigma DS3 Duplex can also be used via the cloud.


Security: With the Entrust Sigma DS3 Duplex you can customise and print watermarks with the YMCKL-KT ribbon. Entrust also offers a magnetic stripe encoder as well as a smart card and RFID card encoder as options for the Sigma DS3 Duplex . It is also possible to combine the Sigma DS3 with a laminator. Encrypted data transfer.



Specifications
Technology Direct-to-card, double-sided printing
Speed Printer Only – Full color printing : Single-sided color ribbon – Up to 250 cards per hour,

Double-sided color ribbon – Up to 180 cards per hour,

Monochrome Printing :Up to 1100 cards per hour single-sided
Resolution 300 dots per inch (dpi) (300 X 600, 300 X 1200)
Card Capacity Input hopper – up to 125 cards, Output hopper – up to 25 cards (up to 100 optional), Reject hopper – up to 10 cards
Standard USB and Ethernet connection
Drivers Windows
Options WiFi, Magstripe and Smart Card encoding
Warranty 24 Months Printer & Printhead Warranty
